Coalbed Methane Outreach Program (CMOP)

Map Legend

	Surface Mine	Underground Mine	Underground Non-Producing Mine	Abandoned Mine
No drainage No gas recovery
With drainage No gas recovery
With drainage With gas recovery

Instructions

Click on any of the map markers to view detailed information on that mine. Some mines are mapped closely, so please utilize the map zooming functionality to better view any clusters.

Zooming: You can click on the "+"/"-" buttons on the upper left corner to zoom map in/out. Quickly return to the map's default start extent using the Home button.

Repositioning the map: Simply click on the map and drag in any direction.

Changing map display: To change the type of map displayed to satellite view, click on the "Imagery" button in the lower left corner. Click the box again to toggle back to the default topographic map.

Definitions

Surface mine: Surface coal mines are mines that remove part or all of mountaintops to expose buried seams of coal. For more information, see Active Surface Mines.

Underground mine: Underground coal mines are mines at which coal is produced by tunneling into the earth to the coalbed, which is then mined with underground mining equipment and transported to the surface. For more information, see Active Underground Mines.

Non-producing mine: Non-producing coal mines are active mines that are temporarily not producing coal, but not yet considered abandoned per the Mine Safety & Health Administration.

Abandoned mine: Abandoned coal mines are no longer operated to produce coal. For more information, see Abandoned Underground Mines.
